DART MAXI

The largest version within the DART range. DART MAXI is designed for architectural lighting of large surfaces and maximum light throw, where it is distance essential to the design. The NSP optic is designed to have a clean, precise 6º beam using a parabolic reflector which collimates the beam and emits a defined, precise cone of light.

  • dimensions W = 8.43"
  • wattage 29W / 36W - NSP
    54W / 69W - SP / FL / MWFL / WFL / ASYM
  • lumens NSP (29W/36W) - 2050Lm / 2458Lm
    SP (54W/69W) - 3991Lm / 4732Lm
    FL (54W/69W) - 4486Lm / 5318Lm
    MWFL (54W/69W) - 5408Lm / 6411Lm
    WFL (54W/69W) - 5418Lm / 6421Lm
    ASYM (54W/69W) - 6405Lm / 7593Lm
  • optics NSP
    SP
    FL
    MWFL
    WFL
    ASYM
  • color temperature 2700K
    3000K
    3500K
    4000K
  • voltage Universal Voltage 120-277V AC
  • ip rating IP66
    IK10
  • cri Ra80
  • Finishes
  • Driver Integral 4/1 Smart Dimming
    (Non-Dimming / 0-10V / Reverse Phase / Forward Phase)
    DALI Dimming
