DART MAXI

The large version in the DART range. DART MAXI Is designed for architectural lighting of large surfaces and where it is essential to install fixtures at a distance. DART MAXI has the NSP optic to have clean, precise 6º beams. It works by reflection which means the lamp is hidden from sight and aimed towards the parabolic reflector which collimates the beam and emits a particularly defined, precise cone of light.

  • dimensions W = 8.43"
  • wattage 29W / 38W - NS 56W / 88W - SP / FL / MF / WF / AS
  • lumens NS (29W/38W) - 2,134Lm / 2,528Lm
    SP (56W/88W) - 3580Lm / 4609Lm
    FL (56W/88W) - 4021Lm / 5177Lm
    MW (56W/88W) - 5150Lm / 6631Lm
    WF (56W/88W) - 5137Lm / 6614Lm
    AS (56W/88W) - 5741Lm / 7391Lm
  • optics NS - not available in 2700K or 3500K
    SP
    FL
    MW
    WF
    AS
  • color temperature 2700K
    3000K
    3500K
    4000K
  • voltage Universal Voltage 120-277V AC
  • ip rating IP66
    IK10
  • cri Ra84, Ra90 upon request
  • Finishes
  • Driver Non-dimmable
    0-10V Dimmable
    DALI Dimmable
