DART MEDIUM

DART MEDIUM is available with two asymmetrical optics. A more open version on the horizontal axis that makes it possible to widen the pitch between fixtures and a new version defined as Narrow Asymmetric that is more comfortable and controlled.

  • dimensions W = 5.3"
  • wattage 19W - NSP
    36W nominal - SP / FL / MF / WF / AS / NA
  • lumens NSP - 1068Lm
    SP - 2581Lm
    FL - 2422Lm
    MW - 4244Lm
    WF - 4269Lm
    AS - 3611Lm
    NA - 3938
  • optics NSP
    SP
    FL
    MWFL
    WFL
    ASYM
    NASYM
  • color temperature 2700K
    3000K
    3500K
    4000K
  • voltage Universal Voltage 120-277V AC
  • ip rating IP66
    IK10
  • cri Ra82
  • Finishes
  • Driver Integral 4/1 Smart Dimming
    (Non-Dimming / 0-10V / Reverse Phase / Forward Phase)
