JUPITER 3″

The JUPITER has a lenticular type optic that makes it possible to obtain defined, precise beams. The beveled trim features no visible screws or hardware, while still retaining a drive over rating. It is easy to install and has a minimal installation depth. Equipped with an optional hex louver or an asymmetrical screen. Also available in a projector version.

  • dimensions 3.15" dia.
  • wattage 7W
  • lumens SP - 548Lm
    FL - 567Lm
    WF - 542Lm
  • optics SP
    FL
    WF
  • color temperature 2700K
    3000K
    2500K
    4000K
  • voltage 24V DC
  • ip rating IP68
    IP69K
    IK10
  • cri Ra90
  • Finishes
  • Driver Remote Electronic 0-10V Dimmable power supply
  • CERTIFICATION Drive Over
