OZ 48V DIGITAL DIM LARGE

OZ 48V DIGITAL DIM LARGE

CONTROL

COMPATIBLE SYSTEM FIXTURES

COMPATIBLE SYSTEM MOUNTING

Downloads

OZ is a professional magnet mounted low voltage 48V modular light system allowing for maximum application flexibility.  OZ 48V Large modules are very small with dimensions of 2” in width with variations of fixed, adjustable or multiple. Two finish options, three beam openings, four color temperatures ranges and 0-10V Digital Dimming for group control.

  • dimensions 2" X 2"
  • wattage Single: 9W - SP
    10W - FL / MW
    Multiple: 22W - SP
    24W - FL / MW
  • lumens SP - 891Lm
    FL - 898Lm
    MW - 990Lm
  • optics SP
    FL
    MW
  • color temperature 2700K
    3000K
    3500K
    4000K
  • voltage 48V
  • ip rating IP20
  • cri Ra90
  • Finishes
    • Driver Remote 0-10V Dimmable Power Supply
      Group Control
